IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
Continued on the next page
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO (cont’d ... )
Formula III LT ‘96 572043500 101mm (3.98) x .625” F 541-5018 Black 44-4100 12-4639
503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm A 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm A For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula III 600, R, LT ‘97-99 572018900 110mm (4.33) x 25mm F 541-5017 Black 44-5905 12-4638
Formula III 700, R ‘98-00 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
Formula III 800 ‘99-00 135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm A 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm A For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula Dlx 380 ‘99 572043500 101mm (3.98) x .625” F 541-5018 Black 44-4100 12-4639
Formula Dlx 500F ‘99 572018900 110mm (4.33) x 25mm F 541-5017 Black 44-5905 12-4638
503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm A,E 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm A,E For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula Dlx 380F ‘00-01 572043500 101mm (3.98) x .625” E 541-5018 Black 44-4100 12-4639
Formula Dlx 500F ‘00-01 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm --- 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm --- For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula Dlx 500 LC ‘99-00 572018900 110mm (4.33) x 25mm E 541-5017 Black 44-5905 12-4638
Formula Dlx 583 ‘99 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm --- 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm --- For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula Dlx 500, 600, 700 ‘01 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm --- 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm --- For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula Grand Touring ‘93 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503112400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula Mach I ‘89-91 4145809,
776300
2.75 x .625 F 541-5011 Black 44-4100 12-4639
Formula Mach I XTC ‘90-91 572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
Formula Mach I XTC ‘93 503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
5031231,
112400
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula Mach I ‘92 572035400 4.25 x .625 541-5052 Black 44-4100 12-4639
Formula Mach I XTC, II ‘92 503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503112400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula Mach I, II ‘93 572043500 101mm (3.98) x .625” F 541-5018 Black 44-4100 12-4639
503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
190mm (7.48) x 25mm A 541-5036 Black 44-5905 12-4638
Formula Mach Z ‘93 503112400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
*For this application the bushing inserts must be removed.
