IDLER WHEEL APPLICATIONS
*For this application the bushing inserts must be removed.
Continued on the next page
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO (cont’d... )
GSX 550F Sport ‘10 503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GSX 600 HO, SDI ‘04 503189171,
190229, 802
135mm (5.31”) x 25mm C 541-5032 Black 44-5905 12-4638
GSX 600 HO, SDI ‘05 503190801 180mm (7.09”) x 25mm A 541-5098 Full Moon, Gray 44-5905 12-4638
503189171,
190229, 802
135mm (5.31”) x 25mm C 541-5032 Black 44-5905 12-4638
GSX 600 HO SDI, Sport Ltd. ‘06-08 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
GSX 600 Ltd.Touring ‘08 503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
GSX 600 Ltd. HO E-Tec, XP ‘08-12 503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
GSX 600 Sport ‘10 503191559,
742
180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
GSX 600, XP, HOE LE ‘13 503191742 180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
GSX 800 HO ‘04 503189171,
190229, 802
135mm (5.31”) x 25mm C 541-5032 Black 44-5905 12-4638
GSX 800 HO ‘05 503190801 180mm (7.09”) x 25mm A 541-5098 Full Moon, Gray 44-5905 12-4638
503189171,
190229, 802
135mm (5.31”) x 25mm C 541-5032 Black 44-5905 12-4638
GSX 800 (all) ‘06-08
‘12
503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
GSX 800 (all) ‘13 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503191742 180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GSX 1200 (all) ‘08-12 503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
503191559,
742
180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
GSX 1200 (all) ‘13 503191742 180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GTX 380F ‘06-08 503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
GTX 500SS ‘05 503190801 180mm (7.09”) x 25mm E 541-5098 Full Moon, Gray 44-5905 12-4638
GTX 600 HO, SDI ‘05
GTX 500SS, Sport ‘06-08 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GTX 550F ‘06-09 503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
GTX 600 HO SDI, Ltd ‘06-08 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GTX 600 Ltd., LE HO E-Tec ‘08-10 503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
GTX 600 Sport HO SDI ‘07-08 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GTX 800 HO ‘05 503190801 180mm (7.09”) x 25mm E 541-5098 Full Moon, Gray 44-5905 12-4638
GTX 800 HO, Ltd ‘06-08 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
GTX 800 HO PTEK ‘07-08 503190752 180mm (7.09”) x 20mm A 541-5090 Silver 44-4152 12-4636
503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
This diagram is for reference only.
Please confirm proper location and size before ordering.
