*For this application the bushing inserts must be removed.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO (cont’d ...)
Formula MX, LT ‘85-89 4145186,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
Formula Plus, LT ‘85-89 5030754,
112310
5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
Formula SP, SS ‘85-86 135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
5030755,
112400
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula MX, E, XTC, XTCE ‘90-91 4145809,
776300
2.75 x .625 F 541-5011 Black 44-4100 12-4639
Formula Plus, E, LT, XTC, XTCE ‘90-91 4145759,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
5031231,
112400
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula MX, XTC, XTCR ‘92 4145759,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
Formula Plus, E, EFI, II, XTC, XTCE ‘92 503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
5031231,
112400
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula MX, II, XTC, XTCR ‘93 503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503112400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula MX Z ‘93 572043500 101mm (3.98) x .625” F 541-5018 Black 44-4100 12-4639
5031231,
112400
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula Plus X ‘92-93 414580900,
572035400
2.75 x .625 F 541-5011 Black 44-4100 12-4639
503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
5031231,
112410
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Formula S ‘95-97 572043500 101mm (3.98) x .625” F 541-5018 Black 44-4100 12-4639
Formula SL ‘95-97 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
Formula SLS ‘96 135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
Formula STX ‘96 503189374 165mm (6.50 x 25mm A,E 541-5086 Gray 44-5905 12-4638
Formula STX LT ‘95-96 165mm (6.50 x 25mm A,E For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula S, SE ‘98 572043500 101mm (3.98) x .625” --- 541-5018 Black 44-4100 12-4639
572097602 135mm (5.31) x 25mm B,C 541-5022 Black 44-5905 12-4638
572097703 165mm (6.50) x 25mm A 541-5023 Black 44-5905 12-4638
Formula S, SL ‘99-00 572043500 101mm (3.98) x .625” --- 541-5018 Black 44-4100 12-4639
503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm A 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm A For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula SS ‘95 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
Formula ST ‘94 135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
Formula STX II ‘94 503112400 190mm (7.48) x 25mm --- 541-5036 Black 44-5905 12-4638
Formula Z ‘94-95
Formula SS ‘96 572018900 110mm (4.33) x 25mm E 541-5017 Black 44-5905 12-4638
Formula Z ‘96 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm --- 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm --- For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
