1025 Continued on the next page
*For this application the bushing inserts must be removed.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO (cont’d ...)
Elan Deluxe ‘78 4141963,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
Elite LC ‘78-82 5700323,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
5700324,
572013600
155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Elite ‘04 503190254 180mm (7.09”) x 25mm A 541-5098 Full Moon, Gray 44-5905 12-4638
Escapade ‘87-88 4145759,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
503112300 5.38 x 25mm B 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B For Optional Colors See Chart A Page 1039
570034500 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Everest ‘74-79 4141963,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
5700323,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
5700324,
572013600
155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Everest, LC ‘80 4143405,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
5700333,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
4142267,
570034500
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Everest, LC ‘81-83 4143405,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
4140324,
572013600
155mm (6.10) x 25mm B,C 541-5057 Black 44-5905 12-4638
570034500 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Expedition 550F, Sport ‘06-08 503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
Expedition 550F Sport ‘11 503191559,
742
180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
Expedition 600 TUV HO SDI REV ‘08-09 503191313 141mm (5.55”) x 20mm B 541-5003 Yellow 44-4152 12-4636
Expedition 600 TUV HO SDI XU, SE ‘10 503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
Expedition 1200 ‘09-11 503191742 180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
Expedition LE, SE 600 HO ETEC, XR ‘11 503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
Expedition V-800 Sport ‘07-08 503191313 141mm (5.55”) x 20mm B 541-5089 Silver 44-4152 12-4636
503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
Expedition LE, SE 1200 XR, XU ‘11 503190395,
1559
180mm (7.09”) x 20mm E 541-5004 Black 44-4152 12-4636
Formula 500, Dlx ‘97 572043500 101mm (3.98) x .625” F 541-5018 Black 44-4100 12-4639
Formula 583 ‘97 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm A 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm A For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Formula 500, Dlx ‘98 572-043500 101mm (3.98) x .625” E,F 541-5018 Black 44-4100 12-4639
Formula 500 LC ‘00 572018900 110mm (4.33) x 25mm E,F 541-5017 Black 44-5905 12-4638
Formula 583, Dlx ‘98 572018900 110mm (4.33) x 25mm E,F 541-5017 Black 44-5905 12-4638
Formula III ‘95 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
Formula III ‘96 503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503189374 165mm (6.50 x 25mm A 541-5086 Gray 44-5905 12-4638
165mm (6.50 x 25mm A For Optional Colors See Chart A Page 1039
503189568 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
