1021
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont ’d...)
Indy Trail RMK ‘03 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Trail RMK ‘04-05 1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Trail RMK ‘06-10 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Tran Sport ‘96 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Tran Sport ‘97-98 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Tran Sport ‘99 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1594056-070 6.38 x 20mm --- 541-5016 Black 44-4152 12-4636
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A,E For Optional Colors See Chart C Page 1023
Turbo IQ ‘11-12 1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
Turbo IQ Dragon ‘09 5.62 x 20mm B For Optional Colors See Chart C Page 1023
Turbo LX ‘10 1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
7.25 x 20mm E For Optional Colors See Chart C Page 1023
Turbo IQ LX, LXT ‘11-12 1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
Turbo Switchback ‘08-09 5.62 x 20mm B For Optional Colors See Chart C Page 1023
1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
Indy Ultra RMK ‘96 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
Indy Ultra SKS ‘96 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Ultra SP ‘96-97 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
Indy Ultra, SPX, SPX SE, Touring ‘97-98 1543023 5.63 x .625 F 541-5037 Black 44-5905 12-4638 12-4655
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Widetrak ‘90-92 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
Indy Widetrak ‘93 1543013 4.62 x 25mm F 541-5053 Black 44-5905 12-4638
Indy Widetrak LX ‘94-96 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
Indy Widetrak GT ‘96 1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Widetrak GT ‘94-95 1543013 4.62 x 25mm F 541-5053 Black 44-5905 12-4638
1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
Indy Widetrak GT ‘97 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
Indy Widetrak LX ‘97-98 1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Widetrak LX ‘99 ‘01 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy Widetrak LX ‘00 1543018 5.38 x .750 B,C,D 541-5007 Black 44-5905 12-4638 12-4641
1594082-293 5.35 x .750 B 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B For Optional Colors See Chart C Page 1023
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Continued on the next page
*For this application the bushing inserts must be removed.
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
