IDLER WHEEL APPLICATIONS
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont’d...)
IQ Cruiser, Dragon, Turbo LX ‘08 1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
IQ Shift ‘08 1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
IQ Turbo Dragon ‘10 5.62 x 20mm B For Optional Colors See Chart C Page 1023
IQ Turbo Dragon, IQ Turbo LX ‘08 1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
7.25 x 20mm E For Optional Colors See Chart C Page 1023
IQ Turbo LXT ‘13-14 1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
IQ Widetrak ‘09 1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
Indy Lite ‘91 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543011 5.63 x .625 B 541-5037 Black 44-5905 12-4638 12-4655
Indy Lite, Dlx ‘92 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543011 5.63 x .625 B 541-5037 Black 44-5905 12-4638 12-4655
1504021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Lite GT ‘92 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
Indy Lite, GT, Dlx ‘94-96 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Lite, GT, Dlx ‘93 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Lite, Dlx ‘97-98 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy Lite Touring ‘98 1543022 5.62 x .625 F 541-5049 Black 44-4100 12-4639
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Lite GT ‘97 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Sport ‘87-89
‘92
1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
Indy Sport GT ‘92-94 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy Sport, SKS ‘94-96 1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Sport ‘90-91 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543022 5.62 x .625 F 541-5049 Black 44-4100 12-4639
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Sport ‘93 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
Indy Sport GT ‘95 1543018 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy Sport ‘97 1543018 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1543022 5.62 x .625 F 541-5049 Black 44-4100 12-4639
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Sport, Touring ‘98 1543022 5.62 x .625 F 541-5049 Black 44-4100 12-4639
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy Sport, Touring ‘99 1543022 5.62 x .625 541-5049 Black 44-4100 12-4639
1594056-070 6.38 x 20mm E 541-5016 Black 44-4152 12-4636
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart B Page 000
*For this application the bushing inserts must be removed.
Continued on the next page
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
