1023
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont ’d...)
Starfire ‘76 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
Star Track ‘87 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Star Track ‘88-90 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
TC175, 250 ‘75 1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
TX ‘72 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TX ‘74-75 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
TX ‘76-79 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TX Charger ‘70-71 1594005 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TX Colt ‘70 1594005 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TX Racer ‘72 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TX Starfire ‘73 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TX340, 440 ‘80 1543014 4.25 x .625 F 541-5052 Black 44-4100 12-4639
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
TXC340 ‘79 1543013 4.62 x 25mm --- 541-5053 Black 44-5905 12-4638
TXL340 ‘79 1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
TXC340 ‘80 1543014 4.25 x .625 F 541-5052 Black 44-4100 12-4639
TXC440 ‘81-82 1543015, 18 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
TXL340 ‘80-82 1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
TXL340 ‘77 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
TXL340 ‘78 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
TXL Indy 340 ‘80-82 1543013 4.62 x 25mm --- 541-5053 Black 44-5905 12-4638
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
CHART A:
1594082-293 5.35 x .750 541-5025 Indy Red 44-5905 12-4638 12-4654
1544082-312 5.35 x .750 541-5026 Indy Blue 44-5905 12-4638 12-4654
1544082-216 5.35 x .750 541-5081 Screaming Yellow 44-5905 12-4638 12-4654
CHART B:
1544083-293 6.38 x 20mm 541-5027 Indy Red 44-4152 12-4636
1544083-312 6.38 x 20mm 541-5080 Indy Blue 44-4152 12-4636
1544083-216 6.38 x 20mm 541-5082 Screaming Yellow 44-4152 12-4636
1544083-256 6.38 x 20mm 541-5083 Candy Apple Red 44-4152 12-4636
CHART C:
1590387-070 5.62 x 20mm 541-5045 Black 44-4152 12-4636
1590387-244 5.62 x 20mm 541-5046 Silver 44-4152 12-4636
1590387-293 5.62 x 20mm 541-5047 Red 44-4152 12-4636
CHART D:
1590388-070 7.25 x 20mm 541-5042 Black 44-4152 12-4636
1590388-244 7.25 x 20mm 541-5043 Silver 44-4152 12-4636
1590388-293 7.25 x 20mm 541-5044 Red 44-4152 12-4636
Continued on the next page
*For this application the bushing inserts must be removed.
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO
Alpine II ‘88 4145759,
572035400 4.25 x .625 F,E 541-5052 Black 44-4100 12-4639
503112310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
570034500 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
REAR SUSPENSION
