IDLER WHEEL APPLICATIONS
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO (cont’d ... )
Alpine II ‘89 4145809,
776300
2.75 x .625 B 541-5011 Black 44-4100 12-4639
414-5759,
572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570035300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503112400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Alpine II ‘90-94 4145809,
776300
2.75 x .625 B 541-5011 Black 44-4100 12-4639
4145759,
572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
572011000 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
Alpine II ‘95 414776300 2.75 x .625 B 541-5011 Black 44-4100 12-4639
503112300 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
572035400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Blizzard 5500 ‘79-80 4143405,
Blizzard 5500 MX ‘81-84 572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
5700323,
572011000 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
572035400 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Blizzard 5500 ‘81 4143405,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
Blizzard 7500 Plus ‘81 5700324,
Blizzard 9500, Plus ‘81-82 572013600 155mm (6.10) x 25mm B 541-5057 Black 44-5905 12-4638
Blizzard 9700 ‘83-84 5700345 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Blizzard 6500 Plus ‘78 4143137,
Blizzard 7500 Plus ‘79 572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
5700333,
5720110 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
5700324,
5720136-00 155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Blizzard 7500 Plus ‘80 4143405,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
Blizzard 9500 Plus ‘79-80 414367900 5.25 x .750 B 541-5055 Black 44-5905 12-4638 12-4654
4142267,
570034500
190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Citation ‘78-79 4141963,
5720354
4.25 x .625 F 541-5052 Black 44-4100 12-4639
5700323,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
5700324,
572013600
155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Citation ‘80-84 5700323,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
5700324,
572013600
155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Citation, E ‘89-91 4145759,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
572011000 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
Citation LS, LSE ‘85-88 572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
5700353,
014010
5.38 x 25mm B 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B For Optional Colors See Chart A Page 1039
503034500 190mm (7.48) x 25mm A,E 541-5036 Black 44-5905 12-4638
Elan ‘74-75 5700306,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
*For this application the bushing inserts must be removed.
Continued on the next page
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
