IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont’d...)
700 Classic ‘06 1590387-244 5.62 x 20mm B 541-5046 Silver 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
700 Cleanfire Dragon ‘07 1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590388-070 7.25 x 20mm A,E 541-5042 Black 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
700 Fusion ‘06 1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590387-293 5.62 x 20mm B 541-5047 Red 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
700, 900 HO Fusion IQ, M-10 ‘06 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
700 HO Touring ‘06 1590387-244 5.62 x 20mm B 541-5046 Silver 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
Indy 700 ProX, X2 ‘04 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 700 RMK ‘97-98 1543018 5.38 x .750 --- 541-5007 Black 44-5905 12-4638 12-4641
Indy 700 SKS ‘97 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
Indy 700 XC ‘97-98 1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy 700 XCR ‘98
Indy 700 RMK ‘99 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
Indy 700 SKS ‘99-00 5.35 x .750 B,C For Optional Colors See Chart C Page 1023
Indy 700 XC ‘99-00 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 700 RMK ‘00-01 1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 700 RMK ‘02-05 1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
700, 900 RMK ‘06 1590387-293 5.62 x 20mm B 541-5047 Red 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
1590388-293 7.25 x 20mm E 541-5042 Red 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
Indy 700 SKS ‘02 1543018 5.38 x .750 C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
Indy 700 Switchback ‘04 1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 700 XC Dlx ‘00 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 700 XC SP ‘99-00 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
Indy 700 XCR ‘99-00 5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 700, 800 XC, SP ‘01-05 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1541485 5.38 x .750 E 541-5007 Black 44-5905 12-4638 12-4641
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 700, 800 XC, SP M-10 ‘04 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
Indy 800 Classic ‘04 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
Indy 800 Classic Edge Touring ‘04 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
800 Indy SP, ES ‘14 1590001 6.38 x 35mm F 541-5041 Black 44-4312
800 Indy SP, FO ‘15
*For this application the bushing inserts must be removed.
Continued on the next page
