Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont’d...)
FST IQ Switchback ‘06 1590388-293 7.25 x 20mm A 541-5044 Red 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
FST IQ Switchback ‘07 1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
Galaxy 340 ‘80 1543014 4.25 x .625 F 541-5052 Black 44-4100 12-4639
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
Galaxy 440 ‘80-81 1543014 4.25 x .625 F 541-5052 Black 44-4100 12-4639
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Gemini 244, 250 ‘79-81 1594013 5.63 x .625 B,C 541-5037 Black 44-5905 12-4638 12-4655
Gemini ‘83 1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 340, Dlx, Touring ‘99-01 1543022 5.62 x .625 --- 541-5049 Black 44-4100 12-4639
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 340, Dlx, Touring ‘02-03 1543022 5.62 x .625 --- 541-5049 Black 44-4100 12-4639
Indy 340 Edge Classic ‘04-05 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
340 Classic ‘06 1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
340 Edge LX ‘07 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
340 ‘08 1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
340 Edge Touring, Touring ‘06-07 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
340 Transport ‘08 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 340 Edge Touring ‘04-05 1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 400 ‘84 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543013 4.62 x 25mm --- 541-5053 Black 44-5905 12-4638
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
Indy 400, SKS, Classic ‘85-89 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 400 ‘90-92 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543022 5.62 x .625 F 541-5049 Black 44-4100 12-4639
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 440 LC ‘97-98 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 440 XC ‘97 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
Indy 440 XCF ‘97-98 1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy 440 XCF, SP ‘99 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 440, SKS ‘93-96 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 440 XCR, SP ‘92-95 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 440 XCR, SP ‘96 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594056-070 6.38 x 20mm A 541-5016 Black 44-4152 12-4636
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Continued on the next page
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
*For this application the bushing inserts must be removed.
REAR SUSPENSION
