x X X X X
1009 Continued on the next page
*For this application the bushing inserts must be removed.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
KAWASAKI
Drifter 340, 440 ‘79-81 06413, 41073-3505 4.25 x .625 D,F 541-5052 Black 44-4100 12-4639
Interceptor 550 ‘82 41073-3512 7.12 x .750 A 541-5056 Black 44-5905 12-4638 12-4654
Intriguer 440 ‘78 06413, 41073-3505 4.25 x .625 D,F 541-5052 Black 44-4100 12-4639
Intruder 440 ‘78 41073-3503, 4 5.63 x .625 B,C 541-5037 Black 44-5905 12-4638 12-4655
Intruder 440 ‘79 41073-3503, 4 5.63 x .625 B,C 541-5037 Black 44-5905 12-4638 12-4655
Intruder 440 ‘80 41073-3503, 4 5.63 x .625 --- 541-5037 Black 44-5905 12-4638 12-4655
Invader 340, 440 ‘78
Invader 340, 440 ‘79-80 41073-3503, 4 5.63 x .625 B,C 541-5037 Black 44-5905 12-4638 12-4655
Invader 440 ‘81 41073-3507 6.38 x .750 --- 541-5001 Black 44-5905 12-4638 12-4654
Invader LTD 4, 6 ‘80 41073-3512 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
Inviter 340 ‘78 06413, 41073-3505 4.25 x .625 F 541-5052 Black 44-4100 12-4639
LTD 440 ‘81 41073-3507 6.38 x .750 B,C 541-5001 Black 44-5905 12-4638 12-4654
41073-3512 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
MOTO SKI
Futura ‘76-79 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
Futura 500, E, LCE ‘80 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
414-2267-00 190mm (7.48)
x 25mm
A 541-5036 Black 44-5905 12-4638
Futura 500, E, LCE ‘81-82 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
414-2267-00 190mm (7.48)
x 25mm
A 541-5036 Black 44-5905 12-4638
Grand Prix Special ‘79-80 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
414-2267-00 190mm (7.48)
x 25mm
A 541-5036 Black 44-5905 12-4638
Grand Prix Special ‘81 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
414-2267-00 190mm (7.48)
x 25mm
A 541-5036 Black 44-5905 12-4638
Mirage 300 ‘79 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
Mirage I, II, IIE, Special ‘80-82 570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
Mirage I, II, IIE, Special ‘83 570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
Mirage II ‘83 570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
Mirage III ‘85 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
503-0754-00 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
Nuvik ‘75-79 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
Sonic ‘75 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
Sonic ‘76-78 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
Super Sonic Cross Country ‘79 570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
