IDLER WHEEL APPLICATIONS
See pages 992-995 for pictures & pricing
This diagram is for reference only.
Please confirm proper location and size before ordering.
Replacement
Application
Year
Replaces
O.D. x I.D.
Pos.
WPS#
Color
Bearing Snap Ring Bushing
ARCTIC CAT
(
cont
’
d
...)
Sabercat (all)
‘04
0604-143
5.35 x .625
F
*
541-5008
Black
44-5905
12-4638 12-4655
1604-837, 3604-039
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
2604-117
7.12 x .625
E
541-5059
Silver
44-5905
12-4638 12-4640
Sabercat (all)
‘05-06 0604-143
5.35 x .625
F
*
541-5008
Black
44-5905
12-4638 12-4655
1604-837, 3604-039
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
1604-839, 3604-060
7.12 x 20mm E
541-5076
Black(no spoke)
44-4152
12-4636
3604-063
7.12 x .20mm A
541-5030
Black
44-4152
12-4636
7.12 x .20mm A
For Optional Colors See Chart A Page 932
Sno Pro 440
‘04-05 0604-143
5.35 x .625
F
*
541-5008
Black
44-5905
12-4638 12-4655
2604-117
7.12 x .625
A,E
541-5059
Silver
44-5905
12-4638 12-4640
Sno Pro 440
‘06
1604-837, 3604-039
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
Sno Pro 500
‘10-14
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
Sno Pro 600
‘09-13 3604-039, 681, 807
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
Super Jag
‘87-89 0604-004
5.35 x .625
B,C
541-5008
Black
44-5905
12-4638 12-4655
0604-061
5.38 x 25mm F
541-5006
Black
44-5905
12-4638
0114-240
5.63 x .625
B,C
541-5037
Black
44-5905
12-4638 12-4655
0114-210
6.38 x .750
A
541-5001
Black
44-5905
12-4638 12-4654
6.38 x .750
A
For Optional Colors See Chart A Page 932
Super Jag
‘90-92 0604-374
5.35 x .625
F
541-5008
Black
44-5905
12-4638 12-4655
0604-240
5.63 x .625
D
541-5058
Silver
44-5905
12-4638 12-4655
0114-240
5.63 x .625
B,C
541-5037
Black
44-5905
12-4638 12-4655
T500, 570
‘08-13 3604-043, 681, 807, 039 5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
5.63 x 20mm B
541-5040
Platinum
44-4152
12-4636
1604-839, 3604-060
7.12 x 20mm E
541-5076
Black(no spoke)
44-4152
12-4636
3604-063, 298
7.12 x .20mm A
541-5030
Black
44-4152
12-4636
7.12 x .20mm A
For Optional Colors See Chart A Page 932
T660 Touring, Turbo
‘04-08 1604-684
5.63 x .625
B
541-5048
Black
44-5905
12-4638 12-4655
1604-837, 3604-039
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
3604-043
5.63 x 20mm B,F
541-5040
Platinum
44-4152
12-4636
1604-690
5.63 x 25mm B,F
541-5033
Black
44-5905
12-4638
2604-251, 3604-055
6.38 x 20mm A
541-5067
Black
44-4152
12-4636
6.38 x 20mm A
For Optional Colors See Chart A Page 932
1604-838, 3604-049
6.38 x 20mm E
541-5034
Black
44-4152
12-4636
6.38 x 20mm E
For Optional Colors See Chart A Page 932
Trail
‘07
1604-837, 3604-039
5.63 x 20mm B
541-5031
Black
44-4152
12-4636
5.63 x 20mm B
For Optional Colors See Chart A Page 932
3604-055
6.38 x 20mm A
541-5067
Black
44-4152
12-4636
6.38 x 20mm A
For Optional Colors See Chart A Page 932
TZ1 Touring
‘08
2604-196, 3604-043, 039 5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
5.63 x 20mm B
541-5040
Platinum
44-4152
12-4636
TZ1 (all)
‘09-14 3604-043, 681, 807
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
5.63 x 20mm B,C
For Optional Colors See Chart A Page 932
5.63 x 20mm B
541-5040
Platinum
44-4152
12-4636
3604-060
7.12 x 20mm E
541-5076
Black(no spoke)
44-4152
12-4636
3604-063, 298
7.12 x .20mm A
541-5030
Black
44-4152
12-4636
7.12 x .20mm A
For Optional Colors See Chart A Page 932
Thundercat, Mtn Cat
‘96-99 0604-240
5.63 x .625
C
541-5058
Silver
44-5905
12-4638 12-4655
0604-459
5.63 x .625
B
541-5037
Black
44-5905
12-4638 12-4655
0604-238
6.38 x .625
A
541-5070
Red
44-5905
12-4638 12-4640
6.38 x .625
A
For Optional Colors See Chart A Page 932
*For this application the bushing inserts must be removed.
Continued on the next page
