IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS
Apollo 340 ‘79-80 1543011 5.63 x .625 B 541-5037 Black 44-5905 12-4638 12-4655
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Centurion 500 ‘79 1543013 4.62 x 25mm F 541-5053 Black 44-5905 12-4638
Centurion Indy 500 ‘81-82 1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Centurion 500 ‘80 1543014 4.25 x .625 F 541-5052 Black 44-4100 12-4639
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
Charger ‘70-73 1594005, 5430204 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
Charger SS ‘72 1594005 7.12 x .750 A,E 541-5056 Black 44-5905 12-4638 12-4654
Cobra ‘78-79 1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
Colt, SS ‘72-78 1594012, 3, 8 5.63 x .625 B,C 541-5037 Black 44-5905 12-4638 12-4655
Custom ‘74 1594016 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
Cutlass, SS ‘81-82 1594021 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Electra ‘74-77 1594016 6.38 x .750 A,E 541-5001 Black 44-5905 12-4638 12-4654
FS, FST Classic ‘06 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1590387-244 5.62 x 20mm B 541-5046 Silver 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
FS, FST IQ Touring ‘07 1590387-244 5.62 x 20mm B 541-5046 Silver 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
FS IQ Touring ‘08-09 1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
FST IQ Touring ‘08-10 5.62 x 20mm B For Optional Colors See Chart C Page 1023
1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
FS Widetrak IQ ‘10-13 1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
FST IQ, LX, Touring, Cruiser ‘07-09 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1590387-244 5.62 x 20mm B 541-5046 Silver 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
FST IQ, LX ‘07 1590001 6.38 x 35mm F 541-5041 Black 44-4312
1590387-244 5.62 x 20mm B 541-5046 Silver 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
MOTO SKI (cont’d...)
Sonic ‘82 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
414-2267-00 190mm (7.48)
x 25mm
A 541-5036 Black 44-5905 12-4638
Sonic LC ‘84 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
503-0754-00 5.38 x 25mm B 541-5006 Black 44-5905 12-4638
Super Sonic LC ‘79 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
570-0333-00 5.25 x 25mm B 541-5038 Black 44-5905 12-4638
570-0324-00 155mm (6.10)
x 25mm
A 541-5057 Black 44-5905 12-4638
Super Sonic LC ‘80 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
414-3679-00 5.25 x .750 B,C 541-5055 Black 44-5905 12-4638 12-4654
570-0345-00 190mm (7.48)
x 25mm
A 541-5036 Black 44-5905 12-4638
Super Sonic ‘81 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
Ultra Sonic ‘81-82 570-0324-00 155mm (6.10)
x 25mm
--- 541-5057 Black 44-5905 12-4638
570-0345-00 190mm (7.48)
x 25mm
--- 541-5036 Black 44-5905 12-4638
Ultra Sonic ‘80 414-3137-00 4.25 x .625 F 541-5052 Black 44-4100 12-4639
414-3679-00 5.25 x 750 B 541-5055 Black 44-5905 12-4638 12-4654
*For this application the bushing inserts must be removed.
Continued on the next page
