Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont ’d...)
Indy 500 RMK ‘00-01 1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 500 XC SP ‘99 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 500 XC ‘99-00 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 500 XC SP ‘00 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 500 XC SP Edge ‘01-05 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
Indy 550 Classic ‘04-05 5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
500 XC Sp Edge ‘06 1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
500 XC SP ‘07 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
550 Indy Adventure ‘15 1590388-070 7.25 x 20mm E 541-5042 Black 44-4152 12-4636
550 Indy Voyageur ‘15
550 Classic ‘06 1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
550 Edge, LX ‘07-08 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
550 Indy, ES ‘14-16 1590001 6.38 x 35mm F 541-5041 Black 44-4312
550 IQ Shift ‘09
550 IQ Shift, ES ‘10-13
550 IQ LXT ‘11-13 1590001 6.38 x 35mm F 541-5041 Black 44-4312
550 Shift, ES ‘11-13 1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
1590387-070 5.62 x 20mm B 541-5045 Black 44-4152 12-4636
5.62 x 20mm B For Optional Colors See Chart C Page 1023
Indy 600 ‘83 1543013 4.62 x 25mm --- 541-5053 Black 44-5905 12-4638
1543015, 20 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 600 ‘84 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543013 4.62 x 25mm --- 541-5053 Black 44-5905 12-4638
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 600, SE, LE ‘85-87 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543015 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 600 Classic Touring ‘01 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 600 Classic Touring ‘02 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
Indy 600 Classic Touring ‘03 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
Indy 600 Classic ‘04-05 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
Indy 600 Classic Edge Touring, RMK ‘04-05 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
600 Cleanfire Switchback ‘07 1590388-244 7.25 x 20mm A 541-5043 Silver 44-4152 12-4636
7.25 x 20mm A For Optional Colors See Chart C Page 1023
Continued on the next page
*For this application the bushing inserts must be removed.
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
