1015
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
POLARIS (cont ’d...)
Indy 600 Switchback ‘04-05 1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 600 Touring ‘00 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 600 Triumph ‘00 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
Indy 600 XC Dlx ‘00 5.35 x .750 B,C For Optional Colors See Chart C Page 1023
Indy 600 XC SP ‘00 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 600 XC, SP ‘99 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 600 XC SP Edge ‘00 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 600 XC SP Edge ‘01-04 1541485 5.38 x .750 B 541-5007 Black 44-5905 12-4638 12-4641
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 600 XC ‘97-98 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 600 XCR, SE, SP ‘96-98 1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy 600 XCR ‘94 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 600 XCR ‘95 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 650 RXL, SKS ‘91-92 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 650, SKS ‘90-92 1543022 5.62 x .625 F 541-5049 Black 44-4100 12-4639
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 650 RXL, SKS, Touring ‘93-96 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 650 RXL ‘97 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1543023 5.63 x .625 F * 541-5037 Black 44-5905 12-4638 12-4655
1594056-070 6.38 x 20mm A,E 541-5016 Black 44-4152 12-4636
Indy 650, SKS ‘88-89 1543017 4.62 x .625 F 541-5050 Black 44-4100 12-4639
1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
1594032 6.38 x 25mm A 541-5010 Silver 44-5905 12-4638
1594021 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Indy 700 Classic ‘01 1543018 5.38 x .750 B,C 541-5007 Black 44-5905 12-4638 12-4641
Indy 700 SKS ‘01 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
1544083-293 6.38 x 20mm A 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
Indy 700 Classic ‘02-04 1594082-293 5.35 x .750 B,C 541-5025 Indy Red 44-5905 12-4638 12-4654
5.35 x .750 B,C For Optional Colors See Chart C Page 1023
Indy 700 Classic Edge Touring ‘04 1544083-293 6.38 x 20mm B,C 541-5027 Indy Red 44-4152 12-4636
6.38 x 20mm A For Optional Colors See Chart C Page 1023
1594087 6.38 x .750 E 541-5001 Black 44-5905 12-4638 12-4654
Continued on the next page
*For this application the bushing inserts must be removed.
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
