1001
Replacement
Application
Year
Replaces
O.D. x I.D.
Pos.
WPS#
Color
Bearing Snap Ring Bushing
ARCTIC CAT
(
cont
’
d
...)
Lynx, Dlx
‘91-93 0604-004, 374
5.35 x .625
D, F
541-5008
Black
44-5905
12-4638 12-4655
Lynx Mtn Cat
‘92-93 0114-240
5.63 x .625
B,C
541-5037
Black
44-5905
12-4638 12-4655
0114-210
6.38 x .750
A
541-5001
Black
44-5905
12-4638 12-4654
6.38 x .750
A
For Optional Colors See Chart A Page 932
Mountain Cat (all)
‘02
1604-684
5.63 x .625
B
541-5048
Black
44-5905
12-4638 12-4655
1604-690
5.63 x 25mm F
541-5033
Black
44-5905
12-4638
Mountain Cat (all)
‘03-04 1604-684
5.63 x .625
B
541-5048
Black
44-5905
12-4638 12-4655
1604-837, 3604-039
5.63 x 20mm B
541-5031
Black
44-4152
12-4636
5.63 x 20mm B
For Optional Colors See Chart A Page 932
1604-690
5.63 x 25mm B
541-5033
Black
44-5905
12-4638
‘03
1604-839, 3604-060
7.12 x 20mm E
541-5076
Black
44-4152
12-4636
7.12 x 20mm E
For Optional Colors See Chart A Page 932
Mountain Cat 500 EFI
‘01
0604-374
5.35 x .625
F
541-5008
Black
44-5905
12-4638 12-4655
Mountain Cat 600 EFI, LE
‘01
0604-459
5.63 x .625
B,C
541-5037
Black
44-5905
12-4638 12-4655
Mountain Cat 570
‘03-04 3604-049
6.38 x 20mm E
541-5034
Black
44-4152
12-4636
6.38 x 20mm E
For Optional Colors See Chart A Page 932
1604-690
5.63 x 25mm F
541-5033
Black
44-5905
12-4638
Mountain Cat 600 VEV
‘01
0604-374
5.35 x .625
F
541-5008
Black
44-5905
12-4638 12-4655
0604-459
5.63 x .625
C
541-5037
Black
44-5905
12-4638 12-4655
0604-238
6.38 x .625
A,E
541-5070
Red
44-5905
12-4638 12-4640
6.38 x .625
A,E
For Optional Colors See Chart A Page 932
Mountain Cat 600
‘03
2604-251
6.38 x 20mm A
541-5067
Silver
44-4152
12-4636
6.38 x 20mm A
For Optional Colors See Chart D Page 000
Mountain Cat 800, LE
‘01
0604-374
5.35 x .625
F
541-5008
Black
44-5905
12-4638 12-4655
Mountain Cat 1000
‘01
0604-459
5.63 x .625
B,C
541-5037
Black
44-5905
12-4638 12-4655
M5 EFI
‘05-06 1604-684
5.63 x .625
B
541-5048
Black
44-5905
12-4638 12-4655
M6
‘05-11 3604-039, 048, 386,
5.63 x 20mm B,C
541-5031
Black
44-4152
12-4636
M7
‘05-06 681, 807
6.38 x 20mm B,C
For Optional Colors See Chart A Page 932
M8, 800 (all)
‘10-13 1604-690
5.63 x 25mm B
541-5033
Black
44-5905
12-4638
M1000 EFI
‘05-11
M1100
‘12-13
M6000, 8000, 9000 Sno Pro (all)
‘14
Pantera
‘75
0104-298
7.12 x .750
A
541-5056
Black
44-5905
12-4638 12-4654
Pantera
‘76-78 0104-837, 0114-245
5.25 x .750
F
541-5055
Black
44-5905
12-4638 12-4654
Pantera
‘79
0114-209
4.25 x .625
F
541-5052
Black
44-4100
12-4639
0114-210
6.38 x .750
A,E
541-5001
Black
44-5905
12-4638 12-4654
6.38 x .750
A,E
For Optional Colors See Chart A Page 932
Pantera
‘80-81 0114-209
4.25 x .625
F
541-5052
Black
44-4100
12-4639
Pantera
‘85
0114-240
5.63 x .625
B
541-5037
Black
44-5905
12-4638 12-4655
0114-210
6.38 x .750
A,E
541-5001
Black
44-5905
12-4638 12-4654
6.38 x .750
A,E
For Optional Colors See Chart A Page 932
Pantera
‘86-88 0604-004
5.35 x .625
D
541-5008
Black
44-5905
12-4638 12-4655
0604-061
5.38 x 25mm F
541-5006
Black
44-5905
12-4638
0114-210
6.38 x .750
A,E
541-5001
Black
44-5905
12-4638 12-4654
6.38 x .750
A,E
For Optional Colors See Chart A Page 932
Pantera
‘89
0604-061
5.38 x 25mm F
541-5006
Black
44-5905
12-4638
Pantera (all)
‘90-00 0604-374
5.35 x .625
F
541-5008
Black
44-5905
12-4638 12-4655
0604-240
5.63 x .625
B
541-5058
Silver
44-5905
12-4638 12-4655
0114-240, 0604-459
5.63 x .625
C
541-5037
Black
44-5905
12-4638 12-4655
0604-238
6.38 x .625
A
541-5070
Red
44-5905
12-4638 12-4640
6.38 x .625
A
For Optional Colors See Chart A Page 932
Pantera 550, 600, 800
‘02-03 1604-684
5.63 x .625
B
541-5048
Black
44-5905
12-4638 12-4655
1604-690
5.63 x 25mm B,C
541-5033
Black
44-5905
12-4638
3604-043
5.63 x 20mm B
541-5040
Platinum
44-4152
12-4636
Continued on the next page
IDLER WHEEL APPLICATIONS
See pages 992-995 for pictures & pricing
This diagram is for reference only.
Please confirm proper location and size before ordering.
*For this application the bushing inserts must be removed.
REAR SUSPENSION
