1035 Continued on the next page
*For this application the bushing inserts must be removed.
Replacement
Application Year Replaces O.D. x I.D. Pos. WPS# Color Bearing Snap Ring Bushing
SKI-DOO (cont’d... )
Nordik ‘81-83 570032300,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
Nordik 50 ‘88-90 570032400,
572013600
155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Nordik 60 ‘88-91
Nordik 50 ‘91 572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
M05070270,
572011000 5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570032400,
572013600 155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Olympique ‘73-74 570030600,
572011000 5.25 x 25mm B 541-5038 Black 44-5905 12-4638
Olympique ‘75-79 414196300,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
RV ‘77-78 5700323,
572011000
5.25 x 25mm B,C 541-5038 Black 44-5905 12-4638
570032400,
572013600
155mm (6.10) x 25mm A,E 541-5057 Black 44-5905 12-4638
Renegade 550 Sport XP-Fan ‘12-14 503191742 180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
Renegade 600 Sport ACE ‘13-14 503191742 180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
Renegade Adrenaline, Back Cntry, X
600 HO E-TEC
‘10-12 503191316 141mm (5.55”) x 20mm B 541-5005 Black 44-4152 12-4636
Renegade Adrenaline, Back Cntry,
SP, X 800R E-TEC, P-TEC
‘10-12 503191559,
742
180mm (7.09”) x 20mm A,E 541-5004 Black 44-4152 12-4636
Renegade Adrn., X 1200, XR ‘10-12
Renegade SP 800R P-TEK ‘11
Safari 377, E ‘84-89 414518600,
572035400
4.25 x .625 F 541-5052 Black 44-4100 12-4639
570035310 5.38 x 25mm --- 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm --- For Optional Colors See Chart A Page 1039
Safari 447, E ‘84-88 414518600,
Safari 503, R ‘88 572035400 4.25 x .625 F 541-5052 Black 44-4100 12-4639
Safari Grand Luxe ‘85-88 570035310 5.38 x 25mm --- 541-5006 Black 44-5905 12-4638
Skandic 503 ‘87 135mm (5.31) x 25mm --- For Optional Colors See Chart A Page 1039
SS25 ‘84 5030755,
112400
190mm (7.48) x 25mm --- 541-5036 Black 44-5905 12-4638
Safari Cheyenne ‘89-90 4145809,
776300
2.75 x .625 F 541-5011 Black 44-4100 12-4639
414518600,
572035400
4.25 x .625 --- 541-5052 Black 44-4100 12-4639
570035310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
503075500,
112400
190mm (7.48) x 25mm A 541-5036 Black 44-5905 12-4638
Safari Cheyenne ‘91 4145809,
776300
2.75 x .625 F 541-5011 Black 44-4100 12-4639
414518600,
572035400
4.25 x .625 --- 541-5052 Black 44-4100 12-4639
570035310 5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
Safari Dlx ‘93 572018900 110mm (4.33) x 25mm --- 541-5017 Black 44-5905 12-4638
Safari L ‘93 5720146,
043300,
5.38 x 25mm B,C 541-5006 Black 44-5905 12-4638
Safari Rally ‘93 135mm (5.31) x 25mm B,C For Optional Colors See Chart A Page 1039
5720147,
037200
190mm (7.48) x 25mm A 541-5036 Black 44-5905 12-4638
Safari Dlx, L ‘94 572018900 110mm (4.33) x 25mm F 541-5017 Black 44-5905 12-4638
Safari Rally E ‘94 5720147,
037200
190mm (7.48) x 25mm A 541-5036 Black 44-5905 12-4638
IDLER WHEEL APPLICATIONS
This diagram is for reference only.
Please confirm proper location and size before ordering.
REAR SUSPENSION
