755 Continued on the next page
All kits come with pistons, rings and circlips.
Wrist Pin is included, except when noted.
Application
Bore x
Stroke mm
Disp.
(cc)
Bore
Size mm Sizes In. WPS# List
Repl. Ring
Set
Repl. Circlips
Wrist Pin
Top End
Bearing
KTM / PENTON 2 CYCLE (cont’d...)
250SX, EXC, ‘96-16 (300cc Big Bore) 72 x 72 293 72 0.224 878PS $202.00 2835CDA Circlips CW-18 B1022
Cylinder, cylinder head, and powervalve modifications required Wrist pin S-508
ArmorGlide skirt coated;Titanium Nitride rings
300EXC, ‘91-94 PRO-LITE 72 x 73 291 72 STD 631PS $202.00 2835CD Circlips CW-18 B1037
Double Ring, Nikasil bore, 72.5 0.020 2854CD Wrist pin S-477
Cylinder sleeving required for oversizes 73 0.040 631P4 $202.00 2874CD
300EXC, ‘96-03 PRO-LITE 72 x 73 297 72 STD 712PS 202.00 2835CD Circlips CW-18 B1037
Nikasil Bore 72.5 0.020 2854CD Wrist pin S-477
Cylinder sleeving required for oversizes 73 0.040 2874CD
300EXC,MXC ‘04-16; 300XC,XC-W ‘06-16 72 x 72 297 72 STD 858PS $192.00 2835CD Circlips CW-18 B1037
Wrist pin S-477
360SX ‘96-97 PRO-LITE 78 x 74 353 78 STD 747PS $202.00 3071TD Circlips CW-18 B1037
Nikasil Bore, Cylinder sleeving required for oversizes 79 0.040 3110TD Wrist pin S-511
380SX/EXC ‘98-02 PRO-LITE 78 x 77 368 78 STD 748PS $202.00 3071TD Circlips CW-18 B1037
Nikasil Bore, Cylinder sleeving required for oversizes 79 0.040 748P4 202.00 3110TD Wrist pin S-511
KTM 4 CYCLE
250SX-F ‘06-12, EXC-F ‘07-12 76 x 55 248.6 76 STD 4981PS $204.00 2992XG Circlips CW-16
12.5:1 Compression Wrist pin S-686
250SX-F ‘06-12, EXC-F ‘07-12 76 x 55 248.6 76 STD 40006PS $230.00 2992XG Circlips CW-16
13:1 Hi Compression 78 0.080 3071XG Wrist pin S-686
250SX-F ‘13-15, EXC-F ‘14-16 78 x 52.3 250 78 STD 40074PS $204.00 7800YB Circlips W-6883
13.9:1 Compression Wrist pin S-677
250SX-F ‘16 78 x 52.3 250 78 STD 40144PS $204.00 7800YBA Circlips W-6883
14.4:1 Compression Wrist pin S-677
250XC-F, XCW-F ‘07-12 76 x 55 248.6 76 STD 4981PS $204.00 2992XG Circlips CW-16
12.8:1 Compression Wrist pin S-686
250XC-F, XCW-F ‘07-12 76 x 55 248.6 76 STD 40006PS $230.00 2992XG Circlips CW-16
13.5:1 Hi Compression Wrist pin S-686
250XC-F, XCW-F ‘13-14 78 x 52.3 250 78 STD 40074PS $204.00 7800YB Circlips W-6883
13.9:1 Compression Wrist pin S-677
350SX-F ‘11-15 88 x 57.5 350 88 STD 40014PS $204.00 8800YD Circlips CW-18
13.5:1 Compression Wrist Pin S-759
350SX-F ‘11-15 88 x 57.5 350 88 STD 40015PS $230.00 8800YD Circlips CW-18
14.5.1 Compression Wrist Pin S-759
350SX-F ‘11-15 88 x 57.5 350 88 STD RC900PS $282.00 8800YDA Circlips CW-18
RACERS CHOICE Wrist Pin S-759C
14:1 High Compression
Boxed Forging; DLC Coated piston pin
Titanium Nitride Rings; ArmorGlide skirt coated
350EXC-F ‘12-16, XC-F, XCW-F ‘12-14 88 x 57.5 350 88 STD 40056PS $204.00 8800YD Circlips CW-18
12.3:1 Compression Wrist Pin S-759
ArmorGlide skirt coated
350EXC-F ‘12-16, XC-F, XCW-F ‘12-15 88 x 57.5 350 88 STD 40090PS $204.00 8800YD Circlips CW-18
13.0:1 Compression Wrist Pin S-759
ArmorGlide skirt coated
400SX ‘00-02; 400EXC ‘00-02 89 x 64 398 89 STD 8900ZC Circlips CW-20
12:1 Compression 91 0.080 9100ZC Wrist pin S-553
450SX ‘03-06 95 x 63.4 449 95 STD 4805PS $210.00 9500ZS Circlips CW-20
12:1 Compression 97 0.080 9700ZS Wrist pin S-641
450SX ‘03-06 95 x 63.4 449 95 STD 4806PS $236.00 9500ZS Circlips CW-20
13:1 Compression 97 0.080 9700ZS Wrist pin S-641
450XC-F ‘07-10; 450SX-F ‘07-12 97 x 60.8 450 97 STD 4937PS $210.00 9700ZS Circlips CW-19
12.5:1 Compression, Skirt Coated Wrist pin S-682
450XC-F ‘07-10; 450SX-F ‘07-12 97 x 60.8 450 97 STD 4938PS $236.00 9700ZS Circlips CW-19
13.5:1 Hi Compression, Skirt Coated Wrist pin S-682
450SX-F ‘13-16 95 x 63.4 450 95 STD 40073PS $210.00 9500ZS Circlips CW-19
12.6:1 Compression, Skirt Coated Wrist pin S-682
450SX-F ‘13-16 95 x 63.4 450 95 STD 40117PS $236.00 9500ZS Circlips CW-19
13.5:1 Compression, Skirt Coated Wrist pin S-682
450SX-F ‘13-16 95 x 63.4 450 95 STD RC902PS $282.00 9500ZVA Circlips CW-19
RACERS CHOICE Wrist pin S-682C
14:1 High Compression
Boxed Forging; DLC Coated piston pin
Titanium Nitride Rings; ArmorGlide skirt coated
