All kits come with pistons, rings and circlips.
Wrist Pin is included, except when noted.
Application
Bore x
Stroke mm
Disp.
(cc)
Bore
Size mm Sizes In. WPS# List
Repl. Ring
Set
Repl. Circlips
Wrist Pin
Top End
Bearing
KAWASAKI 4 CYCLE (cont’d...)
KX250F ‘07-09 77 x 53.6 250 77 STD 4927PS $220.00 7700YC Circlips CW-16
14:1 High Compression Wrist pin S-677
Skirt Coated
KX250F ‘07-09 77 x 53.6 250 77 STD RC850PS $282.00 7700YCA Circlips CW-16
RACERS CHOICE Wrist pin S-677C
14:1 High Compression
Boxed Forging; DLC Coated piston pin
Titanium Nitride Rings; ArmorGlide skirt coated
KX250F ‘10 77 x 53.6 250 77 STD 40009PS $184.00 7700YC Circlips CW-16
13.2:1 Compression Wrist pin S-677
Skirt Coated
KX250F ‘10 77 x 53.6 250 77 STD 40010PS $220.00 7700YC Circlips CW-16
14.2:1 Compression Wrist pin S-677
Skirt Coated
KX250F ‘10 77 x 53.6 250 77 STD RC886PS $281.95 7700YCA Circlips CW-16
RACERS CHOICE Wrist pin S-677C
14.2:1 High Compression
Boxed Forging; DLC Coated piston pin
Titanium Nitride Rings; ArmorGlide skirt coated
KX250F ‘11-14 77 x 53.6 250 77 STD 40019PS $184.00 7700YC Circlips W-6883
13.5:1 Compression Wrist pin S-677
Skirt Coated
KX250F ‘11-14 77 x 53.6 250 77 STD 40020PS $220.00 7700YC Circlips W-6883
14.5:1 High Compression Wrist pin S-677
Skirt Coated
KX250F ‘11-14 77 x 53.6 250 77 STD RC894PS $282.00 7700YCA Circlips CW-16
RACERS CHOICE Wrist pin S-677C
14.5:1 High Compression
Boxed Forging; DLC Coated piston pin
Titanium Nitride Rings; ArmorGlide skirt coated
KX250F ‘15-16 77 x 53.6 250 77 STD 40124PS $184.00 7700YC Circlips W-6883
13.8:1 Stock Compression Wrist pin S-677
ArmorGlide skirt coated
KX250F ‘15-16 77 x 53.6 250 77 STD 40135PS $220.00 7700YC Circlips W-6883
14.5:1 High Compression Wrist pin S-677
ArmorGlide skirt coated
KLX 300, ‘97-06 78 x 61.2 292 78 STD 4630PS $162.00 3071XG Circlips CW-17
11:1 Compression Wrist pin S-533
Electrofusion Bore
KLX 400 ‘03-06 90 x 62.6 398 90 STD 4713PS $182.00 35433XR Circlips CW-20
12:1 Compression 92 0.080 4713P8 202.00 3622XR Wrist pin S-549
Cylinder sleeving required for oversizes
KLX 400 ‘03-06 90 x 62.6 398 90 STD 4714PS $182.00 35433XR Circlips CW-20
13.5:1 High Compression 92 0.080 3622XR Wrist pin S-549
Cylinder sleeving required for oversizes
KLX 400 ‘03-06 94.5 x 62.6 440 94.5 0.180 4795PS $220.00 3720XP Circlips CW-20
440cc Big Bore Wrist pin S-549
12.5:1 Compression; Cylinder Work Required
KLX 400 ‘03-06 94.5 x 62.6 440 94.5 0.180 4796PS $220.00 3720XP Circlips CW-20
440cc Big Bore Wrist pin S-549
13.5:1 High Compression; Cylinder Work Required
KLX450R ‘08-15 96 x 62.1 449 96 STD 4900PS $196.00 9600ZV Circlips CW-19
12:1 Compression, Skirt coated 98 0.080 9800ZV Wrist pin S-682
KLX450R ‘08-15 96 x 62.1 449 96 STD 4901PS $222.00 9600ZV Circlips CW-19
13:1 Compression, Skirt coated 98 0.080 4901P8 240.00 9800ZV Wrist pin S-682
KX450F ‘06-08 96 x 62.1 449 96 STD 4900PS 196.00 9600ZV Circlips CW-19
12:1 Compression, Skirt coated 98 0.080 9800ZV Wrist pin S-682
KX450F ‘06-08 96 x 62.1 449 96 STD 4901PS $222.00 9600ZV Circlips CW-19
13:1 Compression, Skirt coated 98 0.080 4901P8 240.00 9800ZV Wrist pin S-682
KX450F ‘09-12 96 x 62.1 449 96 STD 4980PS 196.00 9600ZV Circlips CW-19
12.5:1 Compression, Skirt coated Wrist pin S-682
KX450F ‘09-12 96 x 62.1 449 96 STD 4990PS $222.00 9600ZV Circlips CW-19
13.5:1 Compression, Skirt coated Wrist pin S-682
