Model Year Jackshaft Tied Clutch Tied Helix Tied Spring
TSS-04
Clutch TSS-04 Helix
TSS-04
Spring Primary Spring Weight Pin Kit Ramp Kit
SKI-DOO 0-3000 FT
MXZ 600 ‘01-02 30-421515 30-960002 30-210076 30-42094130-420436LW 30-210076 30-210141-002 17.0Grams 30-930941 Stock
MXZ 600 Rev (Carb.) ‘04-07 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-002 16.5Grams 30-930941 Stock
MXZ 600 REV SDI ‘04-07 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-002 16.5Grams 30-930941 Stock
Renegade 600 ‘04-07 30-421515 30-960002 30-210193 30-420941 30-420436LW 30-210193 30-210141-002 16.5Grams 30-930941 Stock
XP 600 E-TEC ‘09-15 30-520182 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-001 17.0Grams 30-930941 Stock
XP 600 TNT ‘08-09 30-421515 30-960003 30-210181 30-420941 30-420716LW 30-210181 30-210141-002 17.0Grams 30-930941 Stock
MXZ 700 ‘00-02 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-003 18.5Grams 30-930941 Stock
MXZ 800 ‘00-02 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-001 18.5Grams 30-930941 Stock
MXZ 800 Rev ‘03-07 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-008 19.2Grams 30-930941 Stock
MXZ 800 Rev XP ‘08-10 30-520182 30-421515 30-960013 30-21019330-420941 30-420773LW 30-210193 30-210141-002 21.0Grams 30-930954 Stock
MXZ 800 E-TEC ‘11-14 30-520182 30-421515 30-210193 30-420941 30-420773LW 30-210193 30-210141-013 21.0Grams 30-930954 Stock
Mach Z 1000 ‘05-07 30-421515 30-960013 30-955556 30-420767LW 30-955556 15.0Grams 30-930941 30-TRA3-10005
Renegade 800 ‘04-07 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-008 19.2Grams 30-930941 Stock
Renegade 800 ‘08-10 30-520182 30-421515 30-960013 30-21018230-420941 30-420773LW 30-210182 30-210141-002 21.0Grams 30-930954 30-TRA3-10013
Renegade 800 E-TEC ‘11-15 30-520182 30-421515 30-960013 30-210184 30-210141-013 21.5Grams 30-930941 30-TRA3-10016
Renegade 1000 136” ‘06-07 30-421515 30-960013 30-955556 30-420767LW 30-955556 15.0Grams 30-930941 30-TRA3-10005
Summit 700 ZX ‘00-03 30-421515 30-960002 30-210076 30-42094130-420478LW 30-210076 30-210141-008 17.0Grams 30-930941 Stock
Summit 800 ZX ‘00-03 30-421515 30-960002 30-210076 30-42094130-420478LW 30-210076 30-210141-008 17.0Grams 30-930941 Stock
Summit 600 Rev 144” ‘04-07 30-421515 30-960002 30-210193 30-420941 30-420436LW 30-210193 30-210141-014 16.5Grams 30-930941 Stock
Summit 800 Rev 144” ‘04-07 30-421515 30-960002 30-210193 30-420941 30-420436LW 30-210193 30-210141-008 19.2Grams 30-930941 30-TRA3-10013
Summit 800 Rev 151” ‘03-07 30-421515 30-960002 30-210193 30-420941 30-420436LW 30-210193 30-210141-008 19.2Grams 30-930941 30-TRA3-10013
Summit 800 Rev 159” ‘04-07 30-421515 30-960002 30-210193 30-420941 30-420436LW 30-210193 30-210141-008 19.2Grams 30-930941 30-TRA3-10013
Summit 800 XP 146/154” ‘08-11 30-520182 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-013 20.0Grams 30-930954 30-TRA3-10013
Summit 800 E-TEC 154” ‘11-15 30-520182 30-421515 30-960003 30-210185 30-210141-016 19.2Grams 30-930941 30-TRA3-10016
Summit 1000 RT 151” ‘06-07 30-421515 30-960013 30-955556 30-420767LW 30-955556 15.0Grams 30-930941 30-TRA3-10005
Summit 1000 RT 162” ‘05-07 30-421515 30-960013 30-955556 30-420767LW 30-955556 15.0Grams 30-930941 30-TRA3-10005
XR 1200 4-Tec ‘09-11 30-421515 30-960013 30-210181 30-210141-013 21.0Grams 30-930954 30-TRA3-10005
SKI-DOO 3000-6000 FT
MXZ 600 ‘01-02 30-421515 30-960002 30-210076 30-420941 30-420436LW 30-210076 30-210141-002 14.0 Grams 30-930941 Stock
MXZ 600 Rev SDI ‘04-07 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-002 14.0Grams 30-930941 Stock
MXZ 600 Rev (Carb.) ‘04-07 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-002 14.0Grams 30-930941 Stock
Renegade 600 ‘04-07 30-421515 30-960002 30-210193 30-420941 30-420436LW 30-210193 30-210141-002 14.0Grams 30-930941 Stock
XP 600 E-TEC ‘09-15 30-520182 30-421515 30-960013 30-21019330-420941 30-420767LW 30-210193 30-210141-001 14.0Grams 30-930941 Stock
XP 600 TNT ‘08-09 30-421515 30-960003 30-210186 30-420941 30-420716LW 30-210186 30-210141-002 14.0Grams 30-930941 Stock
MXZ 700 ‘00-02 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-003 15.5Grams 30-930941 Stock
MXZ 800 ‘00-02 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-001 15.5Grams 30-930941 Stock
MXZ Rev 800 ‘04-07 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
MX Z 800 Rev XP ‘08-10 30-520182 30-421515 30-960013 30-21019330-420941 30-420773LW 30-210193 30-210141-002 19.0Grams 30-930941 Stock
MX Z 800 E-TEC ‘11-15 30-520182 30-421515 30-960013 30-210193 30-210141-013 19.0Grams 30-930954 Stock
Renegade 800 ‘04-07 30-421515 30-960016 30-21019330-420941 30-420773LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
Renegade 800 ‘08-10 30-520182 30-421515 30-960013 30-21019330-420941 30-420773LW 30-210193 30-210141-002 19.0Grams 30-930941 30-TRA3-10013
Renegade 800 E-TEC ‘11-15 30-520182 30-421515 30-960045 30-210184 30-210141-016 17.5Grams 30-930941 30-TRA3-10016
Renegade 1000 136” ‘06-07 30-421515 30-960013 30-955556 30-420767LW 30-955556 12.5Grams 30-930941 30-TRA3-10005
Summit 700 ZX ‘00-03 30-421515 30-960003 30-210193 30-420941 30-420478LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
Summit 800 ZX ‘00-03 30-421515 30-960003 30-210193 30-420941 30-420478LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
Summit 600 Rev 144” ‘04-07 30-421515 30-960003 30-210193 30-420941 30-420436LW 30-210193 30-210141-014 13.5Grams 30-930941 Stock
Summit 800 Rev 144” ‘04-06 30-421515 30-960009 30-210193 30-420941 30-420716LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
Summit 800 Rev 151” ‘04-06 30-421515 30-960009 30-210193 30-420941 30-420716LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
Summit 800 Rev 159” ‘04-06 30-421515 30-960009 30-210193 30-420941 30-420716LW 30-210193 30-210141-008 15.5Grams 30-930941 Stock
Summit X 800 144” ‘07 30-421515 30-960041 30-210185 30-420941 30-420716LW 30-210193 30-210141-016 17.0Grams 30-930941 30-TRA3-10016
Summit X 800 151” ‘07 30-421515 30-960041 30-210185 30-420941 30-420716LW 30-210193 30-210141-016 17.0Grams 30-930941 30-TRA3-10016
Summit X 800 159” ‘07 30-421515 30-960041 30-210185 30-420941 30-420716LW 30-210193 30-210141-016 17.0Grams 30-930941 30-TRA3-10016
Summit 800 XP 146/154” ‘08-10 30-520182 30-421515 30-960041 30-210185 30-420941 30-420716LW 30-210193 30-210141-016 17.0Grams 30-930941 30-TRA3-10016
Summit 800 E-TEC ‘11-15 30-421515 30-960041 30-210185 30-210141-016 17.5Grams 30-930941 30-TRA3-10016
RECOMMENDED SETUPS for SKI-DOO
Model Year TIED CLUTCH TIED Helix TIED Spring TSS-04 Clutch TSS-04 Helix TSS-04 Spring Primary Spring Grams Weight kit
POLARIS 6000-9000 FT (cont’d...)
Vertical Escape ‘03-05 30-421438 30-960050 30-210076 30-420407LW 30-210076 30-210135-008 60
900 RMK ‘06 30-421438 30-960019 30-21007630-420935 30-420407LW 30-210076 30-210135-008 70
POLARIS 9000-12,000 FT
600 RMK ‘00-05 30-421511 30-960049 30-210076 30-520116LW 30-210076 30-210135-008 54
600 RMK ‘06 30-421511 30-960049 30-210076 30-420935 30-520116LW 30-210076 30-210135-008 56
600 RMK HO ‘08-10 30-421511 30-960049 30-210076 Stock 30-520116LW 30-210076 30-210135-008 56
600 RMK PRO ‘12-13 30-421511 30-960049 30-210076 Stock 30-520116LW 30-210076 30-210135-008 56
700 RMK ‘02-05 30-421438 30-960049 30-210076 30-520116LW 30-210076 30-210135-008 56
700 RMK ‘08-10 30-421511 30-960049 30-210076 Stock 30-520116LW 30-210076 30-210135-008 56
800 RMK ‘02-05 30-421438 30-960049 30-210076 30-520116LW 30-210076 30-210135-008 58
800 Dragon RMK ‘08-10 30-421511 30-960049 30-210076 Stock 30-520114LW 30-210076 58
800 Pro RMK ‘11-15 30-421511 30-960055 30-210184 Stock 30-420408LW 30-210076 58
Vertical Escape ‘03-05 30-421438 30-960049 30-210076 30-420405LW 30-210076 30-210135-008 58
900 RMK ‘06 30-421511 30-960050 30-210076 30-42093530-420407LW 30-210076 30-210135-008 68
RECOMMENDED SETUPS for POLARIS cont’d...
Continued on the next page
