Description
WPS#
List
A All Arctic Cat and Yamaha models with OEM FLOAT® ski shocks-Bushing Style
530-0112 $350.00
B Arctic Cat Rear Track Upgrade Kit, M-Series ‘07-13
530-0114
*
150.00
C Rear Float Evol Adapter, fits Arctic Cat M-Series with OEM Float® II Rear Track Shock
530-0118 250.00
D Float 3 Evol kit for machines with OEM Float® III ski shocks-Bushing Style
530-0116 350.00
D Float 3 Evol kit for machines with OEM Float® III ski shocks-Spherical Style
530-0117 350.00
E Float 3 Evol kit for rear track; comes with 90 degree adapter;
530-0123
174.95
Fits all Arctic Cat M-Series with OEM Float 3 Shock
• Complete kit to upgrade
FLOAT®, FLOAT® II, and Float®
III shocks to FLOAT EVOL™
• With this kit, you will gain a
plush bottomless feel without
altering ride height or roll
stiffness
• When combined with the infinite
adjustability of the main air
spring, the EVOL™ air chamber
allows the shock’s spring curve
to be tuned for any conceivable
rider weight and/or terrain
condition
• EVOL™ air chamber regulates
spring rate in the final portion
of the stroke and controls the
bottom-out characteristics of the
shock
• Adjusting this pressure is similar
to changing the spring rate on a
coil over shock
• The rear track kit for the Arctic
Cat M-Series will turn your
sled into a mogul soaking, trail
taming machine
• In addition to the added plush
feel on the trail, our special
valving will help get your sled on
top of the snow with its improved
weight transfer characteristics
• 530-0114 Rear track kit works
on all Arctic Cat models with
stock FOX Zero Pro shock in the
front track and FOX FLOAT® in
the rear track shock
UPGRADE KITS
A
B
Before upgrade
After upgrade
* Due to different valving options, valve shims must be ordered separately for this kit
C
D
QS3 UPGRADE KIT
• 3 Position on-the-fly compression adjuster
• Upgrade your Fox compression adjustable shock to the QS3 tool-free
adjuster
• Allows for simple and repeatable suspension setting changes on the fly.
• Wide range of compression adjustment provides noticeable changes of
ride quality and handling without having to count detents
• Just “flip the switch” to adjust your shock for different riding conditions
providing the ultimate in confidence and comfort
Description WPS#
List
.625” Shaft
530-0119 $100.00
.500” Shaft
530-0124
100.00
E
