WATERCRAFT PISTONS
and TOP END ENGINE REBUILD KITS
All replacement pistons come with piston, rings, wrist pin & circlip
Complete REPLACEMENT PARTS
Application Displ. CC Bore Size Top End Kit Piston Kits Ring Set Wrist Pin Circlip Bearing
YAMAHA (cont’d...)
1000 FX 140 HO ‘04-08 998cc 75.9mm 78-87100 78-97200 78-77100 78-61711
76.15mm 78-87104 78-97204
1100 VX 1100 ‘05-15 1052cc 75.9mm 78-87200 78-97200 78-77200 78-61711
Will not work on VXR/VXS models 76.15mm 78-87204 78-97204
* Cylinder replating required 76.4mm 78-87205 78-97205
for oversized piston
1100 2-Stroke 1051cc 81mm 78-82720 $325.40 78-82700 78-92500 78-62000 78-12000
1057cc 81.25mm 78-82721 325.40 78-82704 78-92504
1064cc 81.5mm 78-82722 325.40 78-82705 78-92505
1070cc 81.75mm 78-82723 325.40 78-82706 78-92506
1077cc 82mm 78-82724 325.40 78-92507
1100 2-Stroke 1051cc 81mm 78-82720P 346.61 78-82700P 78-92500 78-72500 78-62000 78-12000
PLATINUM SERIES 1057cc 81.25mm 78-82721P 346.61 78-82704P 78-92504
1064cc 81.5mm 78-82722P 346.61 78-82705P 78-92505
1070cc 81.75mm 78-82723P 346.61 78-82706P 78-92506
1077cc 82mm 78-82724P 346.61 78-82707P 78-92507
1200 All ‘97-99 1130cc 84mm 78-82620 394.55 78-82600 78-92600 78-62000 78-12000
(non power valve) 1137cc 84.25mm 78-82621 394.55 78-82604 78-92604
1142cc 84.5mm 78-82622 394.55 78-82605 78-92605
1150cc 84.75mm 78-82623 394.55 78-82606 78-92606
1156cc 85mm 78-82624 394.55 78-82607 78-92607
1200 All ‘97-99 1130cc 84mm 78-82600P 78-92600 78-62000 78-12000
PLATINUM SERIES 1137cc 84.25mm 78-82621P $412.54 78-82604P 78-92604
(non power valve) 1142cc 84.5mm 78-82622P 412.54 78-82605P 78-92605
1150cc 84.75mm 78-82606P 78-92606
1156cc 85mm 78-82607P 78-92607
1200R PLATINUM SERIES ‘99-00 1176cc 79.9mm 78-82910P $458.33 78-82900P 78-92900 78-62000
(power valve) 1183cc 80.25mm 78-82914P 458.33 78-82904P 78-92904
*Cylinder replating is 1191cc 80.5mm 78-82915P 458.33 78-82905P 78-92905
required for 1183cc 1198cc 80.75mm 78-82916P 458.33 78-82906P 78-92906
oversized and up 1205cc 81mm 78-82917P 458.33 78-82907P 78-92907
1200R PLATINUM SERIES ‘01-05 1176cc 79.9mm 78-82920P 484.28 78-82900P 78-92900 78-62000
(power valve) 1183cc 80.25mm 78-82921P 484.28 78-82904P 78-92904
*Cylinder replating is
required for 1183cc
oversized and up
1300R PLATINUM SERIES 1176cc 84mm 78-82410P $445.81 78-82400P 78-92400 78-72400 78-12800
(power valve) 1183cc 84.25mm 78-82411P 445.81 78-82404P 78-92404
1191cc 84.5mm 78-82412P 445.81 78-82405P 78-92405
1198cc 84.75mm 78-82413P 445.81 78-82406P 78-92406
1205cc 85mm 78-82414P 445.81 78-92407
FX SHO ‘08-14 1800cc Std 78-87310P 607.98 78-87300P 78-97300 78-77300
FX Cruiser SHO ‘08-14 .25mm 78-87311P 607.98 78-87304P 78-97304 78-77300
FZR, FZS ‘08-13 .5mm 78-87312P 607.98 78-87305P 78-97305 78-77300
Supercharged .75mm 78-87313P 607.98 78-87306P 78-97306 78-77300
Platinum Series 1mm 78-87314P 607.98 78-87307P 78-97307 78-77300
FX HO ‘09-13 1800cc Std 78-87410P 651.28 78-87400P 78-97300 78-77300
FX Cruiser HO ‘09-14 .25mm 78-87411P 651.28 78-87404P 78-97304 78-77300
VXR,VXS ‘11-14 .5mm 78-87412P 651.28 78-87405P 78-97305 78-77300
Non Supercharged .75mm 78-87413P 651.28 78-87406P 78-97306 78-77300
Platinum Series 1mm 78-87414P 651.28 78-87407P 78-97307 78-77300
